Discussion Starter · #1 ·
hi i have a mito mk2 eddie pic on my avatar. when the bike was bought few months bak took her in two get fork seals done and the mechanic fitted the seals and said that in the left hand leg when sat on the bike, there was a spring and a washer missing from inside that leg?? ive bought another set of forks

are the fork legs both suppost to be exactly the same or are the internal components diffrent in each leg????


·
Does not know Everything !
Joined
·
14,526 Posts
I know the Evo models have a spring in one leg and a damper cartridge in the other.

So no, they are not the same.


·
Sargent Sarcastic
Joined
·
8,115 Posts
Isn't there only only caliper and disc on the front of the Mito's
I believe OP is correct about the internals but externally there is only one fork with a caliper mount.

They are also different at the bottom because of the front spindle. The right one (as sat on bike) has larger opening than the left.

Off topic slightly but I do have a pair of USD forks, yokes and spindle off an evo 1 up for grabs if you might need them.


·
Registered
Joined
·
2,881 Posts

·
Registered
Joined
·
2,881 Posts
mk2 and evo legs are also different
evo legs are further apart from eachother, so the solid spacer on the evo leg is bigger/wider.
and ofcourse the yolks are different then too
Hi !

dam, no1 has mentioned about problems fitting mk2 '92~94 forks into Evo YOKe's and Evo1 rim/Evo1 speedo drive.

you are talking about the RH-side fork leg ? when saying "solid spacer"..

im putting Mk2 racing forks/Sp marchessini rim(s) into my Evo.

bye

markus

btw. any Mk2 Lawson Replica owners in here ? im looking for a good quality photo from this sticker/text :
http://www.bikepics.com/pictures/139893/

im also looking a same thingy for Evo's '94~98 RH-side sticker "Gp Swing Arm" :
http://www.bikepics.com/pictures/737649/


·
Registered
Joined
·
420 Posts
Hi !

ive just recently noticed that there is "2 types" of Mk2 Forks '92~94. hhmm what might be the reason for difference..

http://www.bikepics.com/pictures/851809/
http://www.bikepics.com/pictures/779068/

i know for sure that Mk2 Racing '93 and Racing Lucky Explorer '92/94 had the forks with those "holes at top". i just dont know the reason or truth if they are different set-up..

bye

markus
Hi i reckon they've drilled those holes to make a jig to hold the top of the forks still. Problem happened to me the other day - when removing the top bolt the top of the forks start to turn with the bolt if they're done up too tightly or stuck a little. looks like they're only there to do that cos you can see the marks where its turned slightly probably from slipping out of the holes.
D


·
Registered
Joined
·
24 Posts
hi i have a mito mk2 eddie pic on my avatar. when the bike was bought few months bak took her in two get fork seals done and the mechanic fitted the seals and said that in the left hand leg when sat on the bike, there was a spring and a washer missing from inside that leg?? ive bought another set of forks

are the fork legs both suppost to be exactly the same or are the internal components diffrent in each leg????
i did the same with ma mito and bought another set of front forks but in side they were as the first set
a spring in the right hand and the left hand is the shock absorber part


·
Registered
Joined
·
2,881 Posts
Hi !

ive linked some photos about real "Mk2 racing '93" Goldy 2spring front fork into this forum.
some of my old texts in this topic are wrong and i cant edit them anymore.

bye:)
markus
